| 표시 오류: | ±0 . 5%(HLD =800) | 외부 치수: | 148mm×30mm×30mm |
|---|---|---|---|
| 표시 반복성: | 0.8%(HLD =800) | 전원: | 충전식 리튬 배터리 |
| Measurement Direction | Supports 360° (vertical downward, oblique downward, horizontal, oblique upward, vertical upward) |
| Detection Range | (170-960)HLD, (17.9-69.5)HRC, (19-683)HB, (80-1042)HV, (30.6-102.6)HS, (13.5-101.6)HRB, (25-105)HSD |
| Hardness Systems | Richter (HL), Brinell (HB), Rockwell B (HRB), Rockwell C (HRC), Vickers (HV), Shore (HS), Rolling rail Shore (HSD) |
| Indication Error | ±0.5% (HLD=800) |
| Indication Repeatability | 0.8% (HLD=800) |
| External Dimensions | 148mm × 30mm × 30mm |
| Power Source | Rechargeable lithium battery |
| Display | Industrial-grade 128×64 graphic dot matrix organic light-emitting diode LCD |
| Continuous Working Hours | Approximately 20 hours |
| Working Conditions | Operating temperature: 10-50°C, Storage temperature: -30°C to 60°C, Relative humidity ≤ 90% |
| Impact Device Type | Standard Leeb Hardness Block Value | Indication Error | Indication Repeatability |
|---|---|---|---|
| D | 760±30HLD, 530±40HLD | ±6 HLD, ±10HLD | 6HLD, 10HLD |
| DC | 760±30HLDC, 530±40HLDC | ±6HLDC, ±10HLDC | 6HLD, 10HLD |
| DL | 878±30HLDL, 736±40HLDL | ±12HLDL | 12HLDL |
| D+15 | 766±30HLD+15, 544±40HLD+15 | ±12HLD+15 | 12HLD+15 |
| G | 590±40HLG, 500±40HLG | ±12HLG | 12HLG |
| E | 725±30HLE, 508±40HLE | ±12HLE | 12HLE |
| C | 822±30HLC, 590±40HLC | ±12HLC | 12HLC |
