제품 상세 정보:
|
| 선량률 범위: | 100nSv/h~30mSv/h | 에너지역: | 30keV~3MeV(광선); 열중성자 ~14MeV(중성자) |
|---|---|---|---|
| 에너지 해상도: | 7.5%@661.7keV | 신뢰: | 70%~100% |
| 저장 용량: | 1,024개의 레인 스펙트럼 데이터로 구성된 400,000세트 | 통신 인터페이스: | USB 인터페이스 |
| 강조하다: | portable radiation spectrometer,digital nuclear emergency monitor,high intelligence radiation detector |
||
FJ-3302 High Intelligence Digital Portable Spectrometer for Radiation Monitoring & Nuclear Emergency Response
The FJ-3302 digital portable spectrometer is a nuclear monitoring instrument based on the sodium iodide (low potassium) detector and using the advanced digital nuclear pulse waveform processing technology. The instrument integrates a sodium iodide (low potassium) detector and a neutron detector, which not only provides environmental dose-equivalent detection and radioactive source positioning, but also identifies the vast majority of natural and artificial radio nuclides. The FJ-3302 digital portable spectrometer combines the latest achievements in scintillation detectors, electronics and software, combined with advanced communication technology, for a high level of intelligence. It has been widely used in the relevant departments of radiation monitoring and protection, providing reliable technical support and decision-making contribution to the national anti-terrorism and nuclear emergency response, nuclear power plant, customs and entry-exit inspection and quarantine.
|
Custom thin film keys |
High-strength ABS anti-electromagnetic interference waterproof housing |
Large color liquid display screen |
Multilayer digital analysis of a gold-plated circuit |
|
High-speed dual-core processor |
Color backlight processor |
USB data wire |
Large capacity lithium battery |
|
High-speed voltage charger |
Anti-overload probe |
A 16G mass memory card |
High-strength waterproof packing box |
① Detector: 5050mmNal, GM tube, neutron detector (optional);
② Dose rate range: 100nSv / h~30mSv / h;
③ Energy range: 30keV~3MeV (ray); thermal neutron ~14MeV (neutron);
④ Energy resolution: 7.5%@661.7keV;
⑤ confidence:70%~100%;
⑥ The instrument will display the automatic switch according to the "range", and protect the probe off;
⑦ Address: 1024 lanes;
⑧ Storage capacity: 400,000 sets of 1,024 lane spectrum data;
⑨ Communication interface: USB interface;
⑩ It has battery power monitoring, fault detection and threshold alarm functions.
11 Power supply: with 14.8V lithium ion charging battery pack (with charger);
12 Working hours:> 10 hours.
13 Dimensions: 228mm 124mm 107mm (length, width and height);
14 Weight: 1.5kg.
15 Operating temperature: -30℃ ~50℃;
16 Working Humidity: 90%R.H(35℃)；
17
Storage temperature: -50℃ ~70℃.
